| SDI Video Inputs : | 8 |
| SDI Main Program Inputs : | 1 |
| Total SDI Outputs : | 9 |
| SDI Video Outputs : | 8 |
| SDI Main Program Outputs : | 1 Loop Out |
| SDI Rates : | 270Mb, 1.5G, 3G, 6G, 12G. |
| SMPTE ST-2110 IP Video Inputs/Outputs : | 8 x 10G Ethernet |
| Analog Audio Outputs : | 1 x 6.35 mm headphone socket. |
| SDI Audio Inputs : | 16 Ch embedded audio on SDI input. |
| SDI Audio Outputs : | 16 Ch embedded audio on SDI loop output. |
| SMPTE ST 2110 IP Audio Inputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet. |
| SMPTE ST 2110 IP Audio Outputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet |
| Warranty : | 1 Year Limited Manufacturer’s Warranty. |
| Power Usage : | 70 W max. |
| Power Supply : | 2 x Internal 100 - 240V AC 50/60Hz with IEC C14 mains input. |
| Control : | Built in Control Panel 12 button control panel, 2.2 inch color display and spin knob for setup and menu settings. |
| IP Video Compliance : | SMPTE 2110-20 (Uncompressed Video) IGMP v2 SMPTE 2110-21 (Traffic Shaping) Sender: Narrow Receiver: Narrow, Wide Synchronous, Asynchronous SMPTE 2110-30 (PCM) Audio Conformance level: Level C SMPTE 2110-40 (Ancillary Data) Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata. Codec Blackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video. Precision Time Protocol IEEE 1588-2008 (PTP v2) ST 2059-1 ST 2059-2 NMOS IS-04 Discovery and Registration v1.3.2 Peer-to-peer via mDNS/DNS‑SD NMOS IS-05 Connection Management v1.1.2 NMOS BCP-002-01 Natural Grouping NMOS BCP-004-01 Receiver capabilities |
| SDI Video Standards : | HD Video Standards 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080PsF25, 1080PsF29.97, 1080PsF30 Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 4K Video Standards 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI. SDI Compliance SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE 2084, SMPTE 2108‑1, SMPTE ST2110‑20, SMPTE ST2110‑21, SMPTE ST2110‑30, SMPTE ST2110‑40. SDI Video Rates SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI. SDI Color Precision 4:2:2 SDI Color Space YUV SDI Auto Switching Automatically detects SD, HD, 2K DCI, Ultra HD and 4K DCI. Level A and B is automatically detected on 3G-SDI input and user selectable on 3G‑SDI output. |
| Computer Interface : | 1 x USB-C 3.0 for configuration and firmware updates. |
| Ethernet : | 8 x 10Gb/s SFP sockets supporting up to 10G BASE-T for SMPTE 2110 IP video in and out. 1 x 1Gb/s RJ‑45 connector supporting 10/100/1000 BASE-T for configuration and firmware updates. |
| Reclocking : | Yes |
| Multi Rate Support : | Auto detection of SD, HD, Ultra HD and 4K. |
| SMPTE ST 2110 IP Audio Outputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet |
| SMPTE ST 2110 IP Audio Inputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet. |
| Multi Rate Support : | Auto detection of SD, HD, Ultra HD and 4K. |
| Reclocking : | Yes |
| Ethernet : | 8 x 10Gb/s SFP sockets supporting up to 10G BASE-T for SMPTE 2110 IP video in and out. 1 x 1Gb/s RJ‑45 connector supporting 10/100/1000 BASE-T for configuration and firmware updates. |
| Computer Interface : | 1 x USB-C 3.0 for configuration and firmware updates. |
| SDI Video Standards : | HD Video Standards 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080PsF25, 1080PsF29.97, 1080PsF30 Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 4K Video Standards 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI. SDI Compliance SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE 2084, SMPTE 2108‑1, SMPTE ST2110‑20, SMPTE ST2110‑21, SMPTE ST2110‑30, SMPTE ST2110‑40. SDI Video Rates SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI. SDI Color Precision 4:2:2 SDI Color Space YUV SDI Auto Switching Automatically detects SD, HD, 2K DCI, Ultra HD and 4K DCI. Level A and B is automatically detected on 3G-SDI input and user selectable on 3G‑SDI output. |
| IP Video Compliance : | SMPTE 2110-20 (Uncompressed Video) IGMP v2 SMPTE 2110-21 (Traffic Shaping) Sender: Narrow Receiver: Narrow, Wide Synchronous, Asynchronous SMPTE 2110-30 (PCM) Audio Conformance level: Level C SMPTE 2110-40 (Ancillary Data) Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata. Codec Blackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video. Precision Time Protocol IEEE 1588-2008 (PTP v2) ST 2059-1 ST 2059-2 NMOS IS-04 Discovery and Registration v1.3.2 Peer-to-peer via mDNS/DNS‑SD NMOS IS-05 Connection Management v1.1.2 NMOS BCP-002-01 Natural Grouping NMOS BCP-004-01 Receiver capabilities |
| Control : | Built in Control Panel 12 button control panel, 2.2 inch color display and spin knob for setup and menu settings. |
| Power Supply : | 2 x Internal 100 - 240V AC 50/60Hz with IEC C14 mains input. |
| Power Usage : | 70 W max. |
| Warranty : | 1 Year Limited Manufacturer’s Warranty. |
