| HDMI Audio Outputs : | 1 |
| SMPTE ST-2110 IP Video Inputs : | 1 x 10G Ethernet1 x 10G Ethernet |
| SMPTE ST 2110 IP Audio Inputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet. |
| Ethernet : | 1 x 10Gb/s RJ‑45 PoE++ connector supporting 10/100/1000/10G BASE-T for SMPTE-2110 IP video in, configuration and firmware updates. |
| Computer Interface : | 1 x USB-C 3.0 for configuration and firmware updates |
| HDMI HD Video Standards : | 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 |
| HDMI Ultra HD Video Standards : | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 |
| HDMI 4K Video Standards : | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI. |
| SMPTE Compliance : | SMPTE ST2110‑20, SMPTE ST2110‑21, SMPTE ST2110‑30, SMPTE ST2110‑40. |
| HDMI Color Precision : | 4:2:2 |
| HDMI Color Space : | YUV |
| SMPTE 2110-20 (Uncompressed Video) : | IGMP v2 |
| SMPTE 2110-21 (Traffic Shaping) : | Sender: Narrow Receiver: Narrow, Wide Synchronous, Asynchronous |
| SMPTE 2110-30 (PCM) : | Audio Conformance level: Level C |
| SMPTE 2110-40 (Ancillary Data) : | Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata. |
| Codec : | BlPrecisblackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video. |
| NMOS IS-04 Discovery and Registration : | v1.3.2 |
| Peer-to-peer via mDNS/DNS‑SD : | NMOS IS-05 Connection Management |
| Warranty : | 1 Year Limited Manufacturer’s Warranty. |
| Relative Humidity : | 0% to 90% non‑condensing |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Operating Temperature : | 5° to 40° C (41° to 104° F) |
| Power Usage : | 18W |
| Operational Voltage Range : | 12 - 16 V |
| Power Supply : | 1 x +12V DC external universal power supply with locking 5.5mm barrel Jack plus international socket adapters for most countries. |
| Displays : | 1 x IP Input Lock LED indicator light |
| NMOS BCP-004-01 : | Receiver capabilities |
| NMOS BCP-002-01 : | Natural Grouping |
| Peer-to-peer via mDNS/DNS‑SD : | NMOS IS-05 Connection Management |
| NMOS IS-04 Discovery and Registration : | v1.3.2 |
| Codec : | BlPrecisblackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video. |
| SMPTE 2110-40 (Ancillary Data) : | Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata. |
| SMPTE 2110-30 (PCM) : | Audio Conformance level: Level C |
| SMPTE 2110-21 (Traffic Shaping) : | Sender: Narrow Receiver: Narrow, Wide Synchronous, Asynchronous |
| SMPTE 2110-20 (Uncompressed Video) : | IGMP v2 |
| HDMI Color Space : | YUV |
| NMOS BCP-002-01 : | Natural Grouping |
| NMOS BCP-004-01 : | Receiver capabilities |
| Displays : | 1 x IP Input Lock LED indicator light |
| Power Supply : | 1 x +12V DC external universal power supply with locking 5.5mm barrel Jack plus international socket adapters for most countries. |
| Operational Voltage Range : | 12 - 16 V |
| Power Usage : | 18W |
| Operating Temperature : | 5° to 40° C (41° to 104° F) |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Relative Humidity : | 0% to 90% non‑condensing |
| Warranty : | 1 Year Limited Manufacturer’s Warranty. |
