| Relative Humidity : | 0% to 90% non‑condensing |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Operating Temperature : | 5° to 40° C (41° to 104° F) |
| Power Usage : | 18W |
| Operational Voltage Range : | 12 - 16 V |
| Power Supply : | 1 x +12V DC external universal power supply with locking 5.5mm barrel Jack plus international socket adapters for most countries. 1 x RJ45 Ethernet connector for power from PoE++ power supplies. |
| Live Tally Indicator : | Tally LED indicator light |
| Talkback : | 5‑pin XLR talkback headset connection for talkback on channels 15/16 in the SDI and 2110 IP video. |
| Control : | Talkback button controls for Volume Up, Volume Down and Push to Talk. |
| LED Indicators : | 1 x IP Input Lock LED indicator light 1 x SDI Input Lock LED indicator light 1 x Tally LED indicator light |
| IP Video Compliance : | SMPTE 2110-20 (Uncompressed Video) IGMP v2 SMPTE 2110-21 (Traffic Shaping) Sender: Narrow Receiver: Narrow, Wide Synchronous, Asynchronous SMPTE 2110-30 (PCM) Audio Conformance level: Level C SMPTE 2110-40 (Ancillary Data) Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata. Codec Blackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video. Precision Time Protocol IEEE 1588-2008 (PTP v2) ST 2059-1 ST 2059-2 NMOS IS-04 Discovery and Registration v1.3.2 Peer-to-peer via mDNS/DNS‑SD NMOS IS-05 Connection Management v1.1.2 NMOS BCP-002-01 Natural Grouping NMOS BCP-004-01 Receiver capabilities |
| SDI Video Standards : | HD Video Standards 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080PsF25, 1080PsF29.97, 1080PsF30 Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 4K Video Standards 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI. SDI Compliance SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE ST2110‑20, SMPTE ST2110‑21, SMPTE ST2110‑30, SMPTE ST2110‑40. SDI Video Rates SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI. SDI Color Precision 4:2:2 SDI Color Space YUV SDI Auto Switching SDI video connections are switchable between 720p, 1080i, 1080p, Ultra HD and 4K DCI. |
| Computer Interface : | 1 x USB‑C for configuration and firmware updates. |
| Ethernet : | 1 x 10Gb/s RJ‑45 connector for SMPTE‑2110 IP video in and out. |
| Reclocking : | Yes |
| Multi Rate Support : | Auto detection of HD, Ultra HD and 4K. |
| SMPTE ST 2110 IP Audio Outputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet. |
| SMPTE ST 2110 IP Audio Inputs : | 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet. |
| SDI Audio Outputs : | 16 Ch embedded audio on SDI output. |
| SDI Audio Inputs : | 16 Ch embedded audio on SDI input. |
| Analog Audio Outputs : | 1 x 5 pin XLR Talkback. |
| Analog Audio Inputs : | 1 x 5 pin XLR Talkback |
| SMPTE ST-2110 IP Video Inputs/Outputs : | 1 x 10G Ethernet |
| SDI Rates : | 1.5G, 3G, 6G, 12G |
| SDI Video Outputs : | 1 |
