| Control : | External Control Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles. iPad control, Bluetooth control, USB PTP camera control. External control of some camera settings, focus, iris and zoom with compatible lenses. Camera Control REST API over USB Ethernet for external control via HTTP when used with REST client applications such as Postman. |
| Supported Codecs : | Codecs Blackmagic RAW Constant Bitrate 3:1 Blackmagic RAW Constant Bitrate 5:1 Blackmagic RAW Constant Bitrate 8:1 Blackmagic RAW Constant Bitrate 12:1 Blackmagic RAW Constant Quality Q0 Blackmagic RAW Constant Quality Q1 Blackmagic RAW Constant Quality Q3 Blackmagic RAW Constant Quality Q5 H.264 Proxy in 1920 x 1080, 8-bit 4:2:0 |
| Media Format : | Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
| Media : | 1 x CFexpress Type B card slot, 1 x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and H.264 Proxy Recording. |
| Built in Speaker : | 1 x mono speaker |
| Microphone : | Integrated stereo microphone. |
| Computer Interface : | USB Type-C for external drive recording, PTP camera control and software updates. |
| Analog Audio Outputs : | 1 x 3.5mm headphone jack. |
| Analog Audio Inputs : | 2 x mini XLR analog switchable between mic with phantom power support and line level (up to +14dBu). 1 x 3.5mm Stereo Input. All audio inputs can also be used for Timecode input. |
| Total Video Outputs : | 1 x HDMI up to 1080p60 |
| Total Video Inputs : | None |
| Timecode Clock : | Highly accurate timecode clock. Less than 1 frame drift every 8 hours. |
| Controls : | Touchscreen menus on 5 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push integrated into handgrip, 1 x ISO Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x Focus Button, 1 x IRIS Button, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button and 1 x Playback Button. |
| Metadata Support : | Automatically populated lens data from electronic L-Mount lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files. |
| Screen Type : | LCD capacitive touchscreen. |
| Screen Brightness : | 1500 nits |
| Screen Dimensions : | 5” 1920 x 1080. |
| Iris Control : | Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses. |
| Focus : | Autofocus is available using compatible L‑Mount lenses in single shot autofocus, continuous autofocus, object tracking autofocus and face tracking autofocus modes. |
| Frame Rates : | Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Off-speed frame rates up to 60 fps in 6K 2.4:1 and 4K DCI 17:9, 100 fps in Super 16 16:9 and 120 fps in 1080HD. |
| Shooting Resolutions : | 6048 x 4032 (Open Gate 3:2) up to 36 fps 4832 x 4032 (Anamorphic 6:5) up to 36 fps 6048 x 3200 (6K DCI 17:9) up to 48 fps 6048 x 2520 (6K 2.4:1) up to 60 fps 4096 x 3072 (Super 35 4:3) up to 50 fps 4096 x 2160 (4K DCI 17:9) up to 60 fps 2112 x 1184 (Super 16 16:9) up to 100 fps 1920 x 1080 (1080 HD 16:9) up to 120 fps |
| Dual Native ISO : | 400 and 3200 |
| Dynamic Range : | 13 Stops |
| Lens Control : | Iris and focus on supported lenses. |
| Lens Mount : | Active L-Mount. |
