| Warranty : | 3 Year Limited Manufacturer’s Warranty. |
| Relative Humidity : | 0% to 90% non-condensing |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Operating Temperature : | 5° to 40° C (32° to 104° F) |
| Power Requirements : | Power Consumption 22 W |
| Real Time Effects : | DaVinci Resolve, Final Cut Pro X internal effects. Adobe Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects. |
| Cross Conversion : | Built in, high quality hardware cross conversion from 720HD to 1080HD on playback, 1080HD to 720HD on playback. |
| HD Up Conversion : | Built in, high quality software up converter from SD to HD on input. Selectable between 16:9 Zoom or anamorphic. |
| HD Down Conversion : | Built in, high quality software down converter on playback and capture. Down converted SD selectable between letterbox and anamorphic 16:9 styles. |
| Colorspace Conversion : | Hardware based real time. |
| HDR Support : | HDR static metadata packing, HLG and PQ transfer characteristics. |
| Color Space : | REC 601, REC 709, REC 2020. |
| SDI Video Sampling : | 4:2:2, 4:4:4 |
| SDI Color Precision : | 8, 10, 12-bit RGB 4:4:4 in all modes up to 1080p30 and 8, 10-bit YUV 4:2:2 in all modes. 12-bit RGB 4:4:4 only supported in playback. |
| Audio Sampling : | Television standard sample rate of 48 kHz and 24 bit. |
| SDI Metadata Support : | RP 188/SMPTE 12M-2 and closed captioning. |
| SDI Compliance : | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, ITU-R BT.656 and ITU-R BT.601. |
| SD Video Standards : | 525i59.94 NTSC, 625i50 PAL |
| Software : | Software Included Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. Internal Software Upgrade Firmware built into software driver. Loaded at system start or via updater software. Physical Installation PCI Express 8 lane generation 2, compatible with 8 and 16 lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please check the Support pages to see the full system requirements. |
| Supported Codecs : | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4. |
| Computer Interface : | PCI Express 8 lane generation 2, compatible with 8 and 16 lane PCI Express slots. |
| Sync Input : | Tri-Sync or Black Burst |
| SDI Audio Outputs : | 16 channels embedded in SD and HD. |
| SDI Audio Inputs : | 16 channels embedded in SD and HD. |
| SDI Video Outputs : | 8 x 3G-SDI mini DIN connections independently configurable as Input or Output and supports up to 12-bit SD and HD. |
