| Warranty : | 3 Year Limited Manufacturer’s Warranty. |
| Relative Humidity : | 0% to 90% non‑condensing |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Operating Temperature : | 5° to 40° C (41° to 104° F) |
| Power Consumption : | 30 W |
| HD Up Conversion : | Built in, high quality software up converter from SD to HD on input. Selectable between 16:9 Zoom or anamorphic. |
| HD to SD Down Conversion : | HD to SD with down converted signal on SDI output B, Component and Composite NTSC/PAL. SD output selectable between letterbox, anamorphic 16:9 and center cut 4:3. |
| Ultra HD Down Conversion : | Built in, high quality hardware down converter outputs Ultra HD to HD with down converted signal on SDI outputs C & D and HDMI output when connected to an HD only TV. |
| Copy Protection : | 3D HDMI Video Standards 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60 SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 435, SMPTE 2081, SMPTE 2082, SMPTE 2082-10, SMPTE 2108-1, ITU-R BT.656 and ITU‑R BT.601. SDI Metadata Support RP 188/SMPTE 12M-2 and closed captioning. Audio Sampling Television standard sample rate of 48 kHz at 24‑bit. SDI Video Sampling 4:2:2, 4:4:4 SDI Color Precision 8, 10, 12-bit RGB 4:4:4 in all modes up to UHD 30p, and 8, 10-bit YUV 4:2:2 in all modes Color Space REC 601, REC 709, REC 2020 HDR Support HDR metadata packing, HLG and PQ transfer characteristics. (HDMI supports static HDR metadata only) HDMI Video Sampling 4:4:4, 4:2:2 and 4:2:0 HDMI Color Precision 8, 10 and 12-bit (Deep Color). HDMI Configuration HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display. Multiple Rate Support HDMI and SDI video connections are switchable between SD/HD/2K and 4K. Component analog video connections are switchable between SD and HD. Copy Protection HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
| Multiple Rate Support : | HDMI and SDI video connections are switchable between SD/HD/2K and 4K. Component analog video connections are switchable between SD and HD |
| HDMI Configuration : | HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display. |
| 4:4:4, 4:2:2 and 4:2:04:4:4, 4:2:2 and 4:2:0 : | |
| HDMI Video Sampling : | 4:4:4, 4:2:2 and 4:2:0 |
| REC 601, REC 709, REC 2020 : | HDR metadata packing, HLG and PQ transfer characteristics. (HDMI supports static HDR metadata only) |
| Color Space : | REC 601, REC 709, REC 2020 |
| SDI Color Precision : | 8, 10, 12-bit RGB 4:4:4 in all modes up to UHD 30p, and 8, 10-bit YUV 4:2:2 in all modes |
| SDI Video Sampling : | 4:2:2, 4:4:4 |
| Audio Sampling : | Television standard sample rate of 48 kHz at 24‑bit. |
| SDI Metadata Support : | RP 188/SMPTE 12M-2 and closed captioning. |
| SDI Compliance : | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 435, SMPTE 2081, SMPTE 2082, SMPTE 2082-10, SMPTE 2108-1, ITU-R BT.656 and ITU‑R BT.601. |
| 3D HDMI Video Standards : | 3D HDMI Video Standards |
| 3D SDI Video Standards : | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 |
| 4K Video Standards : | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI*, 4Kp48 DCI*, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI |
| Ultra HD Video Standards : | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95*, 2160p48*, 2160p50, 2160p59.94, 2160p60 |
| 2K Video Standards (SDI Only) : | 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI |
| HD Video Standards : | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95*, 1080p48*, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 |
| SD Video Standards : | 525i59.94 NTSC, 625i50 PAL |
| Internal Software Upgrade : | Firmware built into software driver. Loaded at system start or via updater software. |
| AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10‑bit 4:4:4. : | DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. |
| Supported Codecs : | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10‑bit 4:4:4. |
| Computer Interface : | PCI Express 8 lane generation 2, compatible with 8 and 16 lane PCI Express slots with HDMI or SDI mezzanine card. |
| Device Control : | Sony™ compatible RS422 deck control port. Serial ports TxRx direction reversible under software control. |
| Sync Input : | Tri-Sync or Black Burst. |
| HDMI Audio Outputs : | 8 Channels embedded in SD/HD/4K. |
| HDMI Audio Inputs : | 8 Channels embedded in SD/HD/4K |
| HDMI Video Inputs : | HDMI type A connector with support for 2160p60. |
| SDI Audio Outputs : | 16 Channels embedded in SD/HD/2K/4K |
| SDI Audio Inputs : | 16 Channels embedded in SD/HD/2K/4K. |
| AES/EBU Audio Outputs : | 2 Channels unbalanced. |
| AES/EBU Audio Inputs : | 2 Channels unbalanced with sample rate converter. |
| Analog Audio Outputs : | 2 Channels of professional balanced analog audio via XLR connectors. |
| Analog Audio Inputs : | 2 Channels of professional balanced analog audio via XLR connectors. |
| Analog Video Outputs : | 1 x Component YUV on 3 BNCs switchable to S-Video and Composite. Component supports HD and SD. |
| Analog Video Inputs : | 1 x Component YUV on 3 BNCs switchable to S-Video or Composite. Component supports HD and SD. |
| SDI Video Outputs : | 2 x 12Gb/s SD/HD/2K/4K. Supports single/dual link 4:2:2/4:4:4. 2D/3D switchable. |
