| Relative Humidity : | 0% to 90% non-condensing |
| Storage Temperature : | 20° to 45° C (-4° to 113° F) |
| Operating Temperature : | 5° to 40° C (32° to 104° F) |
| Power Requirements : | Powered by Thunderbolt cable. Requires computer with a Thunderbolt™ 3 USB-C port. |
| Hardware based real time. : | Requires computer with a Thunderbolt™ 3 USB-C port. Please check support pages to see the full system requirements. |
| Colorspace Conversion : | Physical Installation |
| Hardware Frame Buffer : | v210 (10 bit YUV), 2vuy (8 bit YUV), ARGB, BGRA (8 bit RGB), r210 (10 bit RGB), R12B, R12L (12 bit RGB). |
| Copy Protection : | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
| Multiple Rate Support : | HDMI video connection is switchable between SD and HD. |
| HDMI Color Space : | REC 601, REC 709 and REC 2020 |
| HDMI Configuration : | HDMI 2.0 supports Deep Color. |
| HDMI Color Precision : | 8-bit RGB 4:4:4, 8-bit YUV 4:4:4 and 12-bit YUV 4:2:2 in all standards. |
| HDMI Video Sampling : | 4:2:2 and 4:4:4 |
| HDMI Audio Sampling : | Television standard sample rate of 48 kHz and 24 bit. |
| HD Video Standards : | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
| SD Video Standards : | 525i59.94 NTSC, 625i50 PAL |
| Multiple Rate Support : | SDI video connection is switchable between SD and HD. |
| SDI Color Space : | REC 601, REC 709 and REC 2020 |
| SDI Color Precision : | 8, 10, 12-bit RGB 4:4:4 up to 1080p30, and 8, 10-bit YUV 4:2:2 in all standards. |
| SDI Video Sampling : | 4:2:2, 4:4:4 |
| SDI Audio Sampling : | Television standard sample rate of 48 kHz and 24-bit. |
| SDI Metadata Support : | RP 188/SMPTE 12M-2 and closed captioning. |
| SDI Compliance : | SMPTE 259M, SMPTE 274M, SMPTE 296M, SMPTE 424M and SMPTE 425M A/B |
| 2K Video Standards : | 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI |
| HD Video Standards : | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 |
| SD Video Standards : | 525i59.94 NTSC, 625i50 PAL |
| Other supported applications include : | Cinegy Capture Pro, DevTek EasyMediaSuite, Glookast Capturer, Metus Ingest, Softron MovieRecorder, ToolsOnAir just:in, Burst Video WebClip2Go & [REC]Marker, Zoom. These are third party applications and support may vary, check with your software vendor |
| Internal Software Upgrade : | Firmware built into software driver. Software driver loads upgrades at system start or via updater software. |
| Software Included : | Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. |
| Supported Codecs : | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4. |
| Computer Interface : | Thunderbolt™ 3 (Mac OS, Windows and Linux) |
| HDMI Audio Inputs : | 8 Channels embedded in SD/HD |
| HDMI Video Inputs : | HDMI Video Inputs |
| SDI Audio Inputs : | 16 Channels embedded in SD/HD |
| SDI Rates : | 270Mb, 1.5G, 3G |
